Vertical Motion Practice Problems for AP Physics 1

Introduction
Vertical motion—objects moving up or down under the influence of gravity—forms the backbone of many AP Physics 1 exam questions. Mastering these problems requires a solid grasp of kinematic equations, an intuitive sense of how acceleration due to gravity shapes motion, and the ability to translate real‑world scenarios into mathematical expressions. This guide presents a variety of practice problems, from straightforward textbook style to more nuanced, real‑world contexts, complete with step‑by‑step solutions and key take‑away insights. By working through these examples, students can sharpen both their computational skills and conceptual understanding, positioning themselves for success on the AP exam.

1. Fundamental Concepts Recap

Before diving into problems, let’s review the core formulas that govern vertical motion:

Key Points

• Sign convention: Choose upward as positive. Then (g = -9.8) m/s².
• Initial conditions: (y_0) and (v_0) are the starting position and velocity.
• Units: Keep SI units (meters, seconds, meters per second) for consistency.

2. Practice Problem Set

Problem 1 – Classic “Drop and Drop”

A 2.0 kg rock is dropped from a height of 20 m above the ground. How long does it take to hit the ground, and what is its impact speed?

Solution

1. Time to impact
   (y = y_0 + v_0 t + \tfrac12 a t^2)
   (0 = 20 + 0 \cdot t + \tfrac12 (-9.8) t^2)
   (-20 = -4.9 t^2) → (t^2 = 4.08) → (t = 2.02) s Turns out it matters..

2. Impact speed
   (v = v_0 + a t = 0 + (-9.8)(2.02) = -19.8) m/s
   (Negative sign indicates downward direction.)

Answer: (t \approx 2.0) s, (v \approx 19.8) m/s downward The details matter here..

Problem 2 – “Throwing Up”

A 0.75 kg ball is thrown upward from ground level with an initial speed of 12 m/s. Determine (a) the maximum height reached, (b) the time to reach that height, and (c) the speed upon returning to the ground.

Solution

1. Maximum height
   Set final velocity (v = 0) at top:
   (0 = 12^2 + 2(-9.8)\Delta y) → (\Delta y = \frac{144}{19.6} = 7.35) m Surprisingly effective..

2. Time to top
   (v = v_0 + a t) → (0 = 12 - 9.8 t) → (t = 1.22) s.

3. Speed on return
   Since energy is conserved (ignoring air resistance), speed on return equals initial speed: 12 m/s downward.
   Alternatively, use (v^2 = v_0^2 + 2a \Delta y):
   (v^2 = 0 + 2(-9.8)(-7.35) = 144) → (v = 12) m/s downward Worth keeping that in mind..

Answer: (h_{\max} \approx 7.35) m, (t_{\text{up}} \approx 1.22) s, (v_{\text{down}} = 12) m/s.

Problem 3 – “A Jumping Athlete”

A 70 kg athlete jumps vertically, leaving the ground with an initial upward speed of 3.5 m/s. How high does she rise, and how long does the entire jump last (upward and downward)?

Solution

1. Maximum height
   (\Delta y = \frac{v_0^2}{2g} = \frac{3.5^2}{19.6} = 0.62) m.

2. Time to apex
   (t_{\text{up}} = \frac{v_0}{g} = \frac{3.5}{9.8} = 0.36) s.

3. Total time
   Symmetric motion: (t_{\text{down}} = t_{\text{up}}).
   (t_{\text{total}} = 2 \times 0.36 = 0.72) s Not complicated — just consistent..

Answer: (h_{\max} \approx 0.62) m, total time ≈ 0.72 s The details matter here..

Problem 4 – “Ball on a Rope”

A 0.5 kg ball hangs from a light, inextensible rope that is 5 m long. If the ball is pulled downward 2 m from equilibrium and released, find the ball’s speed when it passes through the equilibrium point.

Solution

Use conservation of mechanical energy:

• Potential energy at release:
  (U_i = m g h_i = 0.5 \times 9.8 \times 2 = 9.8) J Small thing, real impact. And it works..

• Potential energy at equilibrium:
  (U_f = 0) J (take equilibrium as zero).

• Kinetic energy at equilibrium:
  (K_f = U_i - U_f = 9.8) J.

• Speed:
  (K_f = \tfrac12 m v^2) → (v = \sqrt{\frac{2K_f}{m}} = \sqrt{\frac{19.6}{0.5}} = 6.26) m/s.

Answer: (v \approx 6.3) m/s downward No workaround needed..

Problem 5 – “Projectile with a Vertical Component”

A 0.3 kg projectile is launched from a height of 1.5 m with an initial speed of 10 m/s at an angle of 30° above the horizontal. Calculate the vertical component of its velocity, the maximum height reached above the launch point, and the time of flight until it lands back on the ground.

Solution

1. Vertical component
   (v_{0y} = v_0 \sin\theta = 10 \sin 30° = 5) m/s It's one of those things that adds up..

2. Maximum height above launch
   (\Delta y_{\max} = \frac{v_{0y}^2}{2g} = \frac{25}{19.6} = 1.28) m.

3. Time to reach maximum
   (t_{\text{up}} = \frac{v_{0y}}{g} = \frac{5}{9.8} = 0.51) s The details matter here..

4. Total flight time
   The projectile starts 1.5 m above ground. Total vertical displacement to ground: (-1.5) m.
   Use (y = y_0 + v_{0y} t + \tfrac12 (-g) t^2).
   Solve (0 = 1.5 + 5 t - 4.9 t^2).
   Quadratic: (4.9 t^2 - 5 t - 1.5 = 0).
   (t = \frac{5 \pm \sqrt{25 + 29.4}}{9.8}).
   Positive root: (t = \frac{5 + 7.18}{9.8} = 1.27) s.

Answer: (v_{0y}=5) m/s, (h_{\max}=1.28) m above launch, flight time ≈ 1.27 s Easy to understand, harder to ignore..

Problem 6 – “Landing on a Moving Platform”

A 1.0 kg ball is dropped from a moving elevator that is ascending at a constant speed of 2 m/s. The elevator is 15 m above the ground. How long does the ball take to hit the floor of the elevator, and what will be its speed relative to the elevator when it lands?

Solution

1. Time to fall 15 m
   (0 = 15 + 0 \cdot t - 4.9 t^2) → (t = \sqrt{\frac{15}{4.9}} = 1.77) s Worth keeping that in mind..

2. Speed relative to Earth
   (v = 0 - 9.8 \times 1.77 = -17.3) m/s (downward).

3. Relative speed to elevator
   Elevator moves upward at 2 m/s, so relative speed = (v_{\text{ball}} - v_{\text{elevator}} = -17.3 - 2 = -19.3) m/s downward Most people skip this — try not to..

Answer: (t \approx 1.77) s, relative speed ≈ 19.3 m/s downward.

Problem 7 – “Balloon Release”

A helium balloon rises from the ground with an initial upward velocity of 1 m/s. The balloon’s buoyant acceleration is constant at 1.2 m/s² upward. After how long will the balloon reach a height of 30 m?

Solution

Use (y = v_0 t + \tfrac12 a t^2) The details matter here..

(30 = 1 t + 0.Day to day, rearrange: (0. Also, 6 t^2). 6 t^2 + t - 30 = 0).

Solve quadratic:
(t = \frac{-1 + \sqrt{1 + 72}}{1.That's why 5}{1. 2} = \frac{-1 + 8.Because of that, 2} = 5. 92) s Easy to understand, harder to ignore..

Answer: (t \approx 5.9) s.

Problem 8 – “Escalator Lift”

A 60 kg person steps onto an escalator lift that accelerates upward at 0.5 m/s². If the person pushes off the escalator with an initial upward speed of 0.8 m/s relative to the escalator, what is the person’s speed relative to the ground after 3 s?

Solution

Relative to escalator:
(v_{\text{rel}} = 0.8 + 0.Plus, 5 \times 3 = 2. 3) m/s upward The details matter here. And it works..

Escalator speed relative to ground:
(v_{\text{escalator}} = 0 + 0.Which means 5 \times 3 = 1. 5) m/s upward Simple, but easy to overlook..

Total speed:
(v_{\text{total}} = v_{\text{rel}} + v_{\text{escalator}} = 3.8) m/s upward.

Answer: 3.8 m/s upward.

Problem 9 – “Parabolic Launch from a Tower”

A 0.2 kg rock is launched from the top of a 50 m tower at 15 m/s at an angle of 45° above the horizontal. Determine the maximum vertical height above the ground that the rock reaches.

Solution

1. Vertical component of launch
   (v_{0y} = 15 \sin 45° = 10.6) m/s.

2. Maximum height above launch
   (\Delta y_{\max} = \frac{v_{0y}^2}{2g} = \frac{112.4}{19.6} = 5.73) m.

3. Total height above ground
   (h_{\text{total}} = 50 + 5.73 = 55.73) m.

Answer: ≈ 55.7 m.

Problem 10 – “Free‑Fall with Air Resistance (Simplified)”

A 5 kg object falls from a height of 100 m. Assume a constant drag force of 30 N opposing the motion. What is the terminal velocity, and how long does the object take to reach it?

Solution

1. Terminal velocity
   Set net force zero: (mg - F_{\text{drag}} = 0).
   (V_t = \sqrt{\frac{2(mg - F_{\text{drag}})}{C_d \rho A}}) – too complex; instead use a simplified approach:
   Terminal speed occurs when acceleration (a = g - \frac{F_{\text{drag}}}{m} = 0).
   Solve for (V_t) using (a = 0) → (V_t) undefined here; this problem is ill‑posed without a velocity‑dependent drag. Skip.

Answer: This simplified drag model is insufficient; a proper drag equation is required Most people skip this — try not to..

3. Common Pitfalls & How to Avoid Them

1. Sign errors
   – Consistently choose upward as positive.
   – Remember that (g = -9.8) m/s² in this convention.

2. Mixing reference frames
   – When a platform is moving, add or subtract velocities properly.
   – Verify that all velocities are expressed relative to the same frame before combining.

3. Forgetting the initial conditions
   – Always check whether (v_0) or (y_0) is non‑zero.
   – In many AP questions, the initial height is zero unless stated otherwise That's the whole idea..

4. Neglecting air resistance
   – For most AP problems, ignore air resistance unless explicitly mentioned.
   – If air resistance is included, ensure the force is correctly expressed as a function of velocity.

4. Tips for the AP Exam

• Quick Reference Cheat Sheet
  Keep the kinematic equations memorized; write them on your exam sheet if allowed.

• Units Matter
  Convert heights in centimeters to meters, inches to meters, etc., before plugging into formulas.

• Check Your Answers
  If an answer is negative when a positive value is expected, revisit your sign convention.

• Time Management
  Allocate roughly 2–3 minutes per problem; if a problem stalls, move on and return if time allows And it works..

• Practice with Mixed Problems
  Combine vertical motion with horizontal components or rotations to simulate real exam scenarios.

5. Conclusion

Vertical motion problems may appear deceptively simple, yet they test a student’s ability to apply kinematic principles, manage sign conventions, and translate physical situations into equations. By practicing the diverse set of problems above—ranging from basic free‑fall to more complex scenarios involving moving platforms and projectile launch angles—students can build confidence and accuracy. Consistent practice, careful attention to detail, and a solid conceptual framework will prepare any AP Physics 1 student to tackle vertical motion questions with precision and poise That's the whole idea..
